The Budget Gaming System II
by Leonard "Viking1" Hjalmarson


Recently we detailed a budget gaming system build costing around $950 US, and some of you wrote us inquiring about an even cheaper budget gaming system. Here are my recommendations for a 500 MHz gaming machine for a total cost of about $750 US on the street.

Parts List

  • Abit BX6 Rev.2 $100
  • Celeron 400A PPGA $110 with fan
  • WD 8.4 GB 5400 RPM hard disk $118.
  • Diamond MX300 $55 at buy.com
  • 3DfxCOOL CaseHO fan $25
  • 64 meg PCI 100 SDRAM $85
  • STB V3 2000 16 meg $90
  • SONY 40x CD ROM $60
  • Case, 3.5" floppy and 250W PS $60
  • Mouse and kb $50
  • TOTAL: $750 US.
  • Possible: Add Saitek Cyborg3D for $50

Around February 1st, 1999 ABIT Taiwan released revision 2.0 of their excellent mainboard. Improvements included features soft and hard, like a fifth PCI slot and a six chip data buffer set. The Data Buffer acts as a power enhancement to increase the stability and data integrity when using all 4 DIMM slots. Although the Data Buffer set is recommended in Intel design specifications, most other BX motherboards with 4 DIMM slots don't use it because of the cost issue.

The Need for Speed

But the best features of this board are designed for overclockers. BX6 Rev 2.0, as others in ABIT's family, supports the most advanced jumperless technology out there in SoftMenu™ II. Simply put, this software system is incorporated into the BIOS and provides the easiest and safest environment to achieve performance gains. So what can you do with this BIOS menu?

SoftMenuTM II allows you to change the Vcore requirements for the CPU, as well as adjust bus speed settings for a greater range of CPU functioning. There is also a new clock generator that allows for a PCI divider for bus speeds higher than 100MHz, as well as an AGP divider of 1/1 or 2/3 to keep the AGP as close to 66MHz as possible when above 100+MHz. Finally, included in SoftMenu II is the ability to manually specify IRQ placement. This was a much sought after feature that greatly helps in keeping IRQ conflicts to a minimum.

Naturally, hardware monitoring is present via the Winbond chipset. With the Hardware Doctor, a self-diagnostic software program for the PC, the user can monitor the following hardware configurations under Microsoft Windows 95/98:

Click to continue



Abit BH6-2
Abit BX6 Rev.2

  • Power Supply Voltage
  • Voltage monitor for different devices such as CPU, Chipset, ISA Bus, PCI Bus
  • CPU and System fan speed
  • System temperature and a Thermal header for CPU or other hardware temperature monitoring.

My Kingdom for a Slocket

In order to mount a PPGA Celeron in a SLOT 1 mainboard we need a socket-370 to slot-1 converter, or Slocket, for short. This converter allows you to take the Celeron CPU and put it back onto a SEPP package and then insert it into any SLOT 1, including a dual SLOT 1 mainboard. Here is a photo of the MSI 6905 unit.

MS 6905v1.1

With the correct software (Motherboard Monitor ), you will be able to monitor fan speed and CPU temperature in your operating system.

MB Monitor

Go to Page Two
